DHK 100A Brushless Hobbywing waterproof ESC

Features

•  Completely water-proof and dust-proof. The ESC works properly even under water.

• (Please remove the cooling fan when running car in water, and after running, please make the ESC clean and then dry it to

• avoid the oxidation of copper connectors)

•  External Programming Port (EPP), easy to connect with program card, and also works as power port for cooling fan.

•  Excellent start-up, acceleration and linearity features, suitable for truggy (especially short course trucks) and buggy.

•  The built-in switching mode BEC has powerful output to supply all electronic equipments.

•  There is a mounting stand for installing the ESC on chassis easily and firmly.

•  Proportional ABS brake function with 5 steps of maximum brake force adjustment, 8 steps of drag-brake force adjustment. Also

• compatible with the mechanical disc-brake system.

•  Multiple protection features: Low voltage cut-off protection / Over-heat protection / Throttle signal loss protection / Motor blocked

• protection

•  Easily programmed with the SET button of the ESC, and also compatible with pocket-sized Program Card.
