Specification:
Model: OMG-LP-19CF
Size: 41*20.5*26mm (low profile)
Weight: 55g
Gear: Alum
Motor: Coreless
Type: Digital
Case: Metal
Speed (sec/60 Degree):
5.0V: 0.068
6.0V: 0.058
7.4V: 0.050
8.4V: 0.045
Torque (kg.cm):
5.0V: 11
6.0V: 12.0
7.4V: 13.5
8.4V: 15
Application:
1/10 drift, touring car, etc
Limit angle:180±10°(500-2500μsec)
Rotating direction:180°(1000-2000μsec)
Operating travel :220
Neutral position :1520μsec
Maximum:≈180°(500-2500μsec)
Pules width range :500-2500μsec
Dead band width:2μsec
Connector wire length:200 mm
